| Brand Name: | HMD |
| Model Number: | 9581236 |
| MOQ: | 1 |
| Delivery Time: | 5 days |
| Payment Terms: | T/T,Western Union |
| Parameter Name | Standard Specification | Remarks |
|---|---|---|
| Enclosure Size | 42U/24U/12U standard cabinet (600×800×2000mm); Customizable 1U~47U, 400×600mm~800×1200mm (W×D×H) | Customized according to data center equipment size, installation density, and room space; U is the standard unit of data center cabinets |
| Enclosure Material | Cold-rolled steel plate (2.0~3.0mm) / Aluminum alloy (1.5~2.5mm); Optional 304/316 stainless steel | High strength, good rigidity and electromagnetic shielding performance; stainless steel suitable for humid or corrosive environments |
| Protection Level | IP55~IP65; Optional IP66 for harsh environments | Dust-proof, waterproof, anti-splash; meets dust-free and moisture-proof requirements of data center rooms |
| Electromagnetic Shielding | ≥40dB (10kHz~1GHz); Optional ≥60dB for high anti-interference needs | Effectively isolates external electromagnetic interference and radio frequency interference |
| Cooling Method | Forced air cooling (axial fan); Optional precision air conditioning, heat pipe cooling or liquid cooling | Adapts to high heat generation characteristics, ensures internal temperature ≤35℃ |
| Installation Method | Server rack mounting, floor-standing mounting; Optional wall-mounted mounting (small-size enclosure) | Floor-standing type with adjustable feet and anti-slip pads; rack-mounted compatible with standard server racks |
| Door Configuration | Front/rear double glass door (tempered glass) or metal door, with lock and ventilation grille | Tempered glass door for real-time monitoring; lock prevents unauthorized access |
| Internal Configuration | Mounting rails, cable management trough, grounding bar, cooling fan, temperature sensor | Cable management trough standardizes wiring; temperature sensor monitors internal temperature |
| Weight | 30~200kg | Varies according to enclosure size, material thickness and internal configuration |
| Operating Temperature | -20℃~55℃ | Adapts to working temperature range of data center rooms |
| Surface Treatment | Electrostatic spraying (black/gray); Optional anodizing (aluminum alloy enclosure) | Anti-corrosion, anti-scratch, beautiful appearance; matches data center room style |
