| Brand Name: | HMD |
| Model Number: | 635789 |
| MOQ: | 1 |
| Delivery Time: | 7 days |
| Payment Terms: | T/T,Western Union |
| Parameter Name | Standard Specification & Customization Range | Remarks |
|---|---|---|
| Cabinet Size (Customizable) | Standard: 500×600×1800mm; Customizable: 300×400×500mm~1000×1200×2200mm (W×D×H) | Customized according to outdoor installation space and internal equipment size |
| Cabinet Material | 304 stainless steel (1.8~2.5mm); Optional 316 stainless steel/galvanized steel | Anti-corrosion, anti-rust, anti-UV, matching rainproof sunproof requirements for outdoor use |
| Rainproof & Sunproof Performance | Rainproof: IP65+; Sunproof: Anti-UV powder coating, temperature resistance -40℃~80℃ | Effective waterproof and anti-UV, avoiding cabinet damage from heavy rain and strong sunlight |
| Voltage Grade | AC 220V/380V; Optional DC 24V/48V (for control circuit) | Complies with outdoor power supply standards, safe, stable and anti-interference |
| Rated Current | Standard: 32A~250A; Customizable up to 400A for large-scale outdoor equipment | Customized according to total load of outdoor control equipment and components |
| Cooling Method | Standard: Natural ventilation + heat-dissipating grille; Optional silent axial fan | Effective heat dissipation, avoiding component damage from high temperature under sunlight |
| Installation Method | Floor-mounted (reinforced anti-shake base); Optional wall-mounted/pole-mounted (small size) | Stable installation, anti-wind, adapting to various outdoor installation positions |
| Internal Configuration (Customizable) | Power distribution breaker, terminal block, waterproof cable gland, grounding bar | Waterproof configuration enhances rainproof performance, standardized wiring for easy maintenance |
