| Brand Name: | HMD |
| Model Number: | 785369 |
| MOQ: | 1 |
| Delivery Time: | 7 days |
| Payment Terms: | T/T,Western Union |
| Parameter Name | Standard Specification & Customization Range | Remarks |
|---|---|---|
| Box Size (Customizable) | Standard: 400×500×1600mm Customizable: 200×300×400mm~800×1000×2000mm (W×D×H) |
Customized according to outdoor installation space, control equipment size and layout |
| Box Material (Core Parameter) | Cold-rolled steel (1.5~2.0mm)/304 stainless steel Surface treatment: Anti-UV electrostatic spraying |
Anti-UV, anti-corrosion, anti-rust, prevents shell aging and fading under long-term sunlight exposure |
| UV Resistance (Core Parameter) | UV resistance grade: UVA 400~450nm Service life under outdoor direct sunlight: ≥8 years |
Effectively resists UV radiation, avoids shell brittle fracture, fading and performance degradation |
| Rated Current | Standard: 16A~63A Customizable up to 100A for high-power outdoor control equipment |
Matches total load of outdoor control devices and auxiliary electrical equipment |
| Voltage Grade | AC 220V/380V (power supply) DC 24V (for control circuit, optional) |
Complies with outdoor electrical safety standards, stable power supply for control components |
| Protection Level | Standard: IP65 Optional IP66 for heavy rain, heavy dust outdoor environments |
Waterproof, dustproof, anti-splash, fully adapts to harsh outdoor weather conditions |
| Installation Method | Wall-mounted/Floor-mounted/Pole-mounted Optional embedded installation (small size) |
Stable installation, anti-wind, anti-shake, adapts to various outdoor installation positions |
| Internal Configuration (Customizable) | Control module mounting plate, terminal block, cable trough, grounding bar, waterproof gasket | Standardized wiring, waterproof design, ensures stable operation of outdoor control systems |
