| Brand Name: | HMD |
| Model Number: | 2563417 |
| MOQ: | 1 |
| Delivery Time: | 7days |
| Payment Terms: | T/T,Western Union |
| Parameter Name | Standard Specification & Customization Range | Remarks |
|---|---|---|
| Cabinet Size (Customizable) | Standard: 500*600*1800mm; Customizable: 300*400*500mm~800*1000*2000mm (W*D*H) | Customized according to laboratory space, precision equipment size and layout |
| Cabinet Material (Anti-Static) | Anti-static cold-rolled steel (1.5~2.5mm); Optional anti-static 304 stainless steel | Permanent anti-static performance, surface resistance 10⁶~10¹¹Ω, anti-corrosion and easy to clean |
| Voltage Grade | AC 220V/380V (power supply); DC 24V (for control and detection circuit) | Complies with laboratory power supply standards, safe, stable and anti-interference |
| Rated Current | Standard: 16A~100A; Customizable up to 250A for large-scale instruments | Customized according to total load of laboratory control equipment and instruments |
| Protection Level | Standard: IP54; Optional IP55 for chemical/biological laboratories | Dust-proof, anti-splash, anti-touch, matching laboratory cleanliness requirements |
| Cooling Method | Standard: Natural ventilation + precision grille; Optional silent fan | Low noise, no pollution, avoids affecting laboratory environment and experiments |
| Installation Method | Wall-mounted/Floor-mounted; Optional desktop (small-size cabinet) | Space-saving, easy to operate and maintain, fits laboratory layout |
| Internal Configuration (Customizable) | Power distribution breaker, anti-static terminal block, cable trough, grounding bar, control module | Standardized anti-static wiring, avoids static damage to precision instruments |
