| Brand Name: | HMD |
| Model Number: | 156324 |
| MOQ: | 2 |
| Delivery Time: | 7 days |
| Payment Terms: | Western Union,T/T |
| Parameter Name | Standard Specification & Customization Range | Remarks |
|---|---|---|
| Cabinet Size (Customizable) | Standard: 500*600*1800mm; Customizable: 300*400*500mm~1000*1200*2200mm (W*D*H) | Fully customized according to on-site installation space, no space waste |
| Cabinet Material | Cold-rolled steel plate (1.5~2.5mm); Optional 304 stainless steel | Durable, anti-rust, easy to process, adaptable to various customization needs |
| Voltage Grade (LV) | AC 220V/380V (≤1000V); Optional DC 24V/48V for control circuit | Complies with low-voltage control standards, safe and anti-interference |
| Rated Current | Standard: 32A~250A; Customizable up to 400A | Customized according to total load of low-voltage control equipment |
| Protection Level | Standard: IP54; Optional IP55/IP65 according to scene needs | Dust-proof, anti-splash, customizable to adapt to different environments |
| Cooling Method | Standard: Natural ventilation; Optional silent fan/precision cooling | Customizable according to equipment heat generation and scene noise requirements |
| Installation Method | Wall-mounted/Floor-mounted; Customizable according to site layout | Flexible matching with on-site layout, easy to install and maintain |
| Internal Layout (Customizable) | Mounting plate, terminal block, cable trough, breaker (layout fully customizable) | According to equipment size and operation habits, rational layout for easy maintenance |
