| Brand Name: | HMD |
| Model Number: | 457963 |
| MOQ: | 2 |
| Delivery Time: | 7 days |
| Payment Terms: | Western Union,T/T |
| Parameter | Standard Specification | Remarks |
|---|---|---|
| Cabinet Size | Standard: 500×600×1800mm Customizable: 300×400×500mm~800×1000×2000mm |
Customized by commercial space and electrical equipment requirements |
| Cabinet Material | Cold-rolled steel plate (1.5~2.5mm) Optional 304 stainless steel |
Sleek surface, easy cleaning, modern commercial compatibility |
| Voltage Grade | AC 220V/380V Optional DC 24V (control circuit) |
Compliant with commercial power standards |
| Rated Current | 32A~250A Customizable up to 400A |
Selected based on total electrical load requirements |
| Protection Level | Standard: IP44~IP54 Optional IP55 for humid areas |
Dust-proof, touch-protected, commercial environment adapted |
| Cooling Method | Natural ventilation + ventilation grille Optional silent axial fan |
Low noise operation, commercial environment suitable |
| Installation Method | Wall-mounted/Wall-embedded Optional floor-mounted (large cabinets) |
Space-efficient, modern appearance, maintenance-friendly |
| Internal Configuration | Power distribution breaker, terminal block, cable trough, grounding bar | Standardized wiring, organized layout, maintenance accessible |
