| Brand Name: | HMD |
| Model Number: | 564893 |
| MOQ: | 1 |
| Delivery Time: | 7 days |
| Payment Terms: | Western Union,T/T |
| Parameter Name | Standard Specification | Remarks |
|---|---|---|
| Enclosure Size | Standard: 500×600×1800mm; Customizable: 300×400×500mm~800×1000×2200mm | Customized by outdoor installation space and internal electrical component size |
| Enclosure Material | 304 stainless steel (1.8~2.5mm); Optional 316 stainless steel/galvanized steel | Anti-corrosion, anti-rust, anti-ultraviolet, matching IP protection requirements for outdoor use |
| IP Protection Level | Standard: IP65; Optional: IP66/IP67 for extreme outdoor environments | IP65: Full dust-proof, strong waterproof; higher levels for heavy rain/sandstorm scenarios |
| Voltage Grade | AC 220V/380V; Optional DC 24V/48V (for control components) | Complies with outdoor electrical equipment power supply standards, safe and stable |
| Rated Current | 32A~250A; Customizable up to 400A for large outdoor equipment | Selected by total load of internal outdoor electrical components |
| Cooling Method | Natural ventilation + sealed ventilation grille; Optional silent axial fan | Ensures heat dissipation while maintaining IP protection, low noise for outdoor use |
| Installation Method | Floor-mounted (anti-shake base); Optional wall-mounted/pole-mounted (small size) | Stable installation, anti-wind, suitable for various outdoor installation positions |
| Internal Configuration | Terminal block, grounding bar, cable trough, waterproof cable gland (customizable) | Waterproof cable gland enhances IP protection, standardized wiring for easy maintenance |
