| Model Number: | JL8416515659 |
| MOQ: | 20 |
| Price: | USD28-68889 |
| Delivery Time: | 20 days |
| Payment Terms: | T/T,Western Union |
An advanced RCU control panel designed for centralized management of room automation systems in hospitality, commercial, and residential environments. This durable solution provides intuitive control over lighting, HVAC, window treatments, and other smart room functions.
| Attribute | Specification |
|---|---|
| Usage | Electrical Cabinet, PLC control panel |
| Material | Aluminum alloy, stainless steel, carbon steel |
| Thickness | 1.5mm or more (customizable) |
| Structure | Single Door or 2 doors |
| Surface Treatment | Powder Coating |
| Lock Type | Key Lock |
| IP Rating | IP54/IP55/IP65/IP66 (selectable) |
| Installation | Wall Mounted or free standing |
| Width × Height × Thickness (mm) | Cabinet Thickness (mm) | Door Panel Thickness (mm) |
|---|---|---|
| 250×300×150 | 0.6 | 0.8 |
| 300×400×200 | 0.6 | 0.8 |
| 400×500×200 | 0.6 | 0.8 |
| 500×600×200 | 0.6 | 0.8 |
| 600×800×200 | 0.6 | 0.8 |
| 1000×800×200 | 0.6 | 0.8 |
| 1200×1000×200 | 0.6 | 0.8 |
Size Specifications: Adjust width × height × thickness according to installation space requirements. For narrow areas, customize thin cabinets (thickness ≤ 120mm); for large equipment integration, expand to 1500×1200mm or larger.
Material Thickness: In humid environments, upgrade cabinet/door panel thickness to 1.0-1.2mm using 304 stainless steel; in dry indoor scenarios, maintain the base thickness of 0.6/0.8mm to reduce weight.
Protection Performance: For outdoor or dusty environments, increase to IP65 protection level with additional sealing strips and waterproof breathable valves; for corrosive environments, adopt galvanizing + plastic spraying double treatment.
Internal Configuration: Reserve extra mounting holes and guide rails to adapt to components of different brands; add internal partitions or wire troughs according to wiring needs.
Appearance Design: Custom colors available / door panels can be equipped with observation windows or custom nameplates.
