| Brand Name: | HMD |
| Model Number: | 326412 |
| MOQ: | 2 |
| Delivery Time: | 7 days |
| Payment Terms: | Western Union,T/T |
| Parameter Name | Standard Specification | Remarks |
|---|---|---|
| Cabinet Size | Standard: 600*800*1800mm (W*D*H) Customizable: 400*500*600mm~1000*1200*2500mm |
Customized according to outdoor installation space, internal equipment size and storage capacity requirements |
| Cabinet Material | 304/316 stainless steel (2.0~3.0mm) Optional: Galvanized steel plate + heavy-duty anti-corrosion coating |
Core anti-corrosion performance, resistant to acid, alkali, salt spray and humidity; 316 stainless steel is suitable for coastal, chemical and other harsh corrosion environments |
| Protection Level | Standard: IP65 Optional: IP66/IP67 for extreme outdoor environments |
Full dust-proof, strong waterproof, anti-splash and anti-immersion; effectively prevents rainwater, dust and sand from entering |
| Anti-Corrosion Treatment | Stainless steel: Passivation + polishing Galvanized steel: Hot-dip galvanizing + electrostatic anti-corrosion spraying |
Anti-corrosion service life ≥15 years; resistant to ultraviolet radiation, no fading, no peeling |
| Rated Voltage | AC 220V/380V Customizable DC 24V/48V for outdoor electrical/communication equipment |
Adapts to the power supply needs of outdoor electrical, communication and monitoring equipment |
| Rated Current | 32A~200A Customizable up to 300A for large-scale outdoor equipment |
Selected according to the total power of internal outdoor equipment, avoiding overload |
| Cooling & Heating | Standard: Natural ventilation + heat insulation layer Optional: Axial fan + heater for extreme temperature |
Adapt to -30℃~70℃ outdoor temperature range; avoid equipment failure caused by overheating or freezing |
| Installation Method | Standard: Floor-mounted (with anti-theft base) Optional: Wall-mounted/Pole-mounted (small-size cabinets) |
Floor-mounted with anti-shake and anti-theft design; pole-mounted/wall-mounted saves space |
| Door Configuration | Sealed metal door (stainless steel/galvanized steel), with anti-theft lock, waterproof rubber strip and drainage hole | Waterproof rubber strip ensures tight sealing; drainage hole prevents rainwater accumulation; anti-theft lock prevents equipment theft |
| Internal Configuration | Mounting plate, guide rail, cable trough, grounding bar, terminal block, waterproof cable gland (customizable with surge protector) | Waterproof cable gland prevents rainwater from entering along cables; surge protector optional for lightning protection |
| Weight | 50~200kg | Varies according to cabinet size, material thickness and internal configuration |
| Wind Resistance | ≥12 level Optional reinforcement design for typhoon-prone areas |
Strong structural rigidity, anti-shake and anti-collapse; adaptable to strong wind and typhoon outdoor environments |
