| Brand Name: | Siemens |
| Model Number: | 1FL6034-2AF21-1AA1 |
| MOQ: | 5 |
| Price: | 122 USD |
| Delivery Time: | 5 days |
| Payment Terms: | T/T,Western Union |
| Technical Data | O22-2AF | O24-2AF | O32-2AF | O34-2AF | O42-2AF | O44-2AF | O52-2AF | O54-2AF |
|---|---|---|---|---|---|---|---|---|
| Rated Power (kW) | 0.05 | 0.1 | 0.2 | 0.4 | 0.75 | 1 | 1.5 | 2 |
| Horsepower (HP) | 0.07 | 0.14 | 0.27 | 0.54 | 1.02 | 1.36 | 2.04 | 2.72 |
| Rated Torque (Nm) | 0.16 | 0.32 | 0.64 | 1.27 | 2.39 | 3.18 | 4.78 | 6.37 |
| Rated Speed (rpm) | 3000 | |||||||
| Maximum Torque (Nm) | 0.48 | 0.96 | 1.91 | 3.82 | 7.2 | 9.54 | 14.3 | 19.1 |
| Maximum Speed (rpm) | 5000 | |||||||
| Rated Current (A) | 1.2 | 1.2 | 1.4 | 2.6 | 4.7 | 6.3 | 10.6 | 11.6 |
| Maximum Current (A) | 3.6 | 3.6 | 4.2 | 7.8 | 14.2 | 18.9 | 31.8 | 34.8 |
| Torque Constant (Nm/A) | 0.14 | 0.29 | 0.48 | 0.49 | 0.51 | 0.51 | 0.46 | 0.55 |
| Inertia (10⁻⁴ kg·m²) (with brake) | 0.031 (0.038) | 0.052 (0.059) | 0.214 (0.245) | 0.351 (0.381) | 0.897 (1.06) | 1.15 (1.31) | 2.04 (2.24) | 2.62 (2.82) |
| Heat Rating | 8 (130 °C) | |||||||
| Protection Class | IP65 | |||||||
| Peak Overload Torque vs. Motor Inertia Ratio | Up to 30 times | Up to 20 times | Up to 15 times | |||||
| Encoder Type | Incremental encoder TTL 2500 ppr; 21-bit single-turn absolute encoder | |||||||
| Mounting Type | IM B5 (IM V1 and IM V3) | |||||||
| Weight (kg) (with brake) | 0.47 (0.70) | 0.63 (0.86) | 1.02 (1.48) | 1.46 (1.92) | 2.8 (3.68) | 3.39 (4.20) | 5.35 (6.76) | 6.56 (8.00) |
| Operating Temperature | 0 - 40°C (no restrictions) | 0 - 30°C (no restrictions) | ||||||
| Storage Temperature | Up to 90% RH (no condensation at 30°C) | |||||||
| Vibration Class | Class A | |||||||
| Radial Runout Tolerance | Class N | |||||||
| Installation Altitude | Altitude below 1000 m (no derating), altitude within 1000 - 5000 m (derating for use) | |||||||
| Certification | CE EAC | |||||||
| Specification | O22-2AF | O32-2AF | O42-2AF | O52-2AF |
|---|---|---|---|---|
| Holding Torque (Nm) | 0.32 Nm | 1.27 Nm | 3.18 Nm | 6.37 Nm |
| Rated Voltage (V) | 24 V DC ±10% | |||
| Brake Open Time (ms) | 35 | 75 | 105 | 90 |
| Brake Close Time (ms) | 10 | 10 | 15 | 35 |
| Rated Current (A) | 0.25 | |||
| SIMOTICS S-1FL6 High-Inertia Motor | SIMOTICS S-1FL6 Low-Inertia Motor |
|---|---|
| High-quality metal connector | Economical and compact cable |
| Self-locking quick connector | |
| All motors standardly configured with IP65 | |
| High-quality bearing | |
| Shaft protection | High-quality bearing |
| Highly wear-resistant oil seal material | |
